Slot Bracket Options

Fill out the form below, to customize your bracket.


Choose a Standard Blank From Inventory

Flat pattern used to make your part number up to the B for Black or Y for Yellow Zinc in the part number

Blank Features
(input to filter)

Step 1 choose your flat pattern from inventory
If your part number ends with a B or a Y it is a flat pattern and there are no more steps

Anything after the B or Y in the part number is defined in the bend section below

Bracket Length:

Any

Asset 6.png
Asset 1.png

Slot Style:

Slot Width:

Any

Slot Length:

Any

Step 2 Choose your bends
(Anything after the B or Y in the part number)

Bracket Style
Single Bent custom sensor bracket
Z bend custom sensor bracket, two bends in opposite directions
U Bend custom sensor bracket, two bends in the same direction
Flat custom sensor bracket, no bends
MxxAxx                MxxAxxZxxAxx       MxxAxxUxxAxx

M is for mount end M30A90 is 30mm from mount end 90° bend. The second bend is a distance from the other end defined by Z or U

Bend Geometry


Note: Tab length exceeds limitations of flat pattern length and min flange length of 32mm on one or more flanges. Try decreasing flange length of Z/U or choose a longer flat length.

Example of Z bent bracket
Add to Cart
Custom bent sensor bracket

We are generating your custom bracket.
